Astera PlutoFresnel - 80W RGBAM LED Ellipsoidal with 15 to 60-Degree Zoom

Product Overview

Astera's PlutoFresnel is an exceptional solution for film, studio, and event lighting. PlutoFresnel boasts an impressive output comparable to a traditional 300W Tungsten Fresnel. With a beam angle of 15° to 60° without color fringing, wireless and wired DMX control, these lights offer impressive performance while consuming only 80W. Easy to mount and adjust with removable handles and YokeBases, they enhance creativity and productivity on any set.

Product Features

• Built-in battery - Built-in battery for 2 hours on MAX Runtime.
• External Battery Option - Connect one or two RuntimeExtenders with V-Mount or Gold Mount battery for additional Runtime. One 14.4 V battery can operate the light on reduced power. A single 26V battery or two 14.4V batteries allow full power output.
• Removable Lens - Slide out Barndoor and Lens to create an Open Source fixture.
• Yoke Quick-Release - The light can easily be taken out of its Yoke.
• Removable Handle - TrackHandle can be removed or inserted into the Airline Tracks.
• Barndoor - The Barndoor contains a total of 8 leaves, 4 of them can be slid out if needed.
• Wired DMX - Data can be added with a Datalink or PowerBox via Power/Data Combination cables.

Product Specifications

Optical

• LED Engine: Titan LED Engine
• Colors: RGB, Mint, Amber
• Total LED Power: 105 W
• LED Power Draw: 80 W
• CRI (Ra)/ TLCI: 3200-6500K* >96
• Beam Angle: 15° to 60°
• Strobe: 0-25 Hertz
• Pixels: 1

Electrical

• Battery Runtime: up to 20 hours
• Battery Runtime (max. Brightness): 3 h
• Battery Lifetime: 80 % after 400 cycles
• DC Input: 24 VDC; 80W
• DC Connector: 5.5 mm x 2.1 mm
• Power Consumption (max): 80W

Control

• Wired DMX: Yes (via FP3-DTL/PWB-2-86)
• CRMX Receiver: Built-in
• BluetoothBridge BTB: Built-in
• Wireless Protocols: CRMX, UHF, Bluetooth, WIFI, RDM
• Wireless Range: CRMX/UHF up to 300m/330 yds, Bluetooth up to 3m/3.3 yds
• Infrared Control: Yes
• TouchSlider: Yes

Construction

• Housing Material: Polymer & Metal
• IP Rating unwired: IP55 (only with PB15-PLG)
• IP Rating wired: IP55 (only with PWB-CAB-0.2/-1.5/-5/-10/-15)
• Ambient Operating Temperature: 32-104F
• Weight (with AF80-FL, AF80-BD): 10.22 lbs
• Weight (with AF80-FL, AF80-BD, AF80-YK, 2x AF80-YKB, AF80-THD): 14.31 lbs
• Dimensions L x W x D: 11.1" x 6.0" x 6.4"
• Dimensions L x W x H (with AF80-YK, 2x AF80-YKB): 11.1" x 9.6" x 12.7"
• Mounting Options: 4 x AirlineTracks, 1/2" hole, 3/8" thread, 1 x BrickMount (PB15-BMO)

What's included

• (1) Yoke (AF80-YK)
• (1) YokeBase (AF80-YKB)
• (1) Fresnel Lens (AF80-FL)
• (1) BarnDoor (AF80-BD)
• (1) TrackHandle (AX-THD)
